5700-5900MHz 100W RF Power Amplifier High Power Output C Band Microwave Power Amplifier
Place of Origin：China
Brand Name：SWT
Model Number：SW-PA-57005900-51C
Price：make request to get price
Product Description
5700-5900MHz 100W RF Power Amplifier High Power Output C Band Microwave Power Amplifier
The 5700-5900MHz 100W RF power amplifier is designed for wireless communication, radar systems, satellite transmission, and RF testing, providing high power output, low noise, and stable signal amplification for long-distance signal transmission.
Key Features:
Operating Frequency: 5700-5900MHz, ideal for wireless communication, radar, and microwave systems.
High Power Output: 100W (Psat 50dBm), ensuring stable and reliable long-range signal coverage.
High Gain & Low Noise: Optimized circuit design enhances signal quality while minimizing distortion and interference.
Efficient Cooling System: Advanced thermal management enables continuous and stable long-term operation.
Durable & Versatile Design: Compatible with various RF systems, suitable for industrial, military, aerospace, and research applications.
This high-performance RF power amplifier is an ideal solution for wireless communication, radar signal amplification, and high-frequency RF applications, ensuring efficient and stable signal transmission.
Specification
Typical performance at +28 VDC +25oC, and in a 50Ω system.
| Technical indicators | coding | Min | TYP | Max | Unit |
| operating frequency | BW | 5.7 | 5.9 | GHz | |
| Saturated output power | Psat | 100 | W | ||
| input power | Pin | 0 | dBm | ||
| Gain Flatness | ΔG | ±1.5 | dB | ||
| power gain | Gp | 50 | dB | ||
| Gain adjustment range (potentiometer adjustment) | Gadj | 0 | 20 | dB | |
| Spurious rejection @Pout=50dBm | Spur | -60 | dBc | ||
| Harmonic rejection @Pout=50dBm | 2nd/3nd | -15 | dBc | ||
| Input VSWR | VSWRin | 2.0 | |||
| Input/Output Impedance | I/O-IMP | 50 | Ω | ||
| electricity supply | Vdc | 28 | 30 | V | |
| power wastage | Pdiss | 310 | 330 | W | |
| Operating Temperature Range | OT | -20 | +55 | ºC | |
Product Details
Name:
5700-5900MHz RF Power Amplifier
Operating Frequency:
5700-5900MHz
Psat Output Power:
50dBm
Gain:
50dB
Input Vswr:
2
Power Gain Flatness:
±1.5dB
Spurious Signals:
-60dBc
Harmonic Signals:
-15dBc
Operating Temp:
-20~55°C
Application:
wireless communications, radar systems, satellite communications, broadcasting, medical equipment
Transport Package:
Carton
Specification:
155*145*25mm
Payment & Shipping Terms
Minimum Order Quantity
1/pcs
Packaging Details
Standard Packing
Delivery Time
5-8 work days
Payment Terms
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability
100pcs per month
