13.75-14.5GHz RF Amplifier Module Ku Band PSat 5W Microwave Amplifier For Industrial Communication

13.75-14.5GHz RF Amplifier Module Ku Band PSat 5W Microwave Amplifier For Industrial Communication

Description

The 13.75-14.5GHz Ku Band PSat 50 dBm RF Power Amplifier is designed to amplify signals within the frequency range of 13.75GHz to 14.5GHz, specifically targeting the Ku band. Below are the detailed specifications and features of this power amplifier:

1. Frequency Range:

• This power amplifier is suitable for amplifying signals across the frequency range of 13.75GHz to 14.5GHz, falling within the Ku band.

2. PSat and Power Output:

• The amplifier is capable of providing a PSat (saturated output power) of 50 dBm, which corresponds to approximately 100 watts (W) of power. This high output power makes it suitable for applications requiring strong signal amplification.

3. Key Features:

• Ku Band Design: Specifically designed for Ku band signal amplification, ensuring compatibility and performance within this frequency range.

• High PSat: The 50 dBm PSat level provides ample power for signal transmission and processing in Ku band communication and radar systems.

• High Gain and Efficiency: Exhibits high gain and efficiency characteristics, optimizing signal amplification while minimizing energy consumption.

4. Applications:

• Satellite Communications: Used in Ku band satellite communication systems for signal amplification in ground stations and satellite uplinks.

• Radar Systems: Applied in radar systems for signal amplification and processing, enhancing radar performance in target detection and tracking.

• Microwave Links: Utilized in microwave links and point-to-point communication systems requiring high-power amplification in the Ku band.

5. Technical Characteristics:

• High Linearity: Ensures accurate and stable signal amplification, critical for maintaining signal integrity in communication and radar applications.

• Wide Operating Temperature Range: Capable of operating within a wide temperature range, suitable for various environmental conditions.

• Compact Design: Designed to be compact and efficient, facilitating integration into different RF systems and equipment.

In summary, the 13.75-14.5GHz Ku Band PSat 50 dBm RF Power Amplifier is a high-performance amplifier suitable for Ku band applications, offering high PSat, gain, and efficiency for reliable signal amplification in satellite communication, radar, and microwave link systems.

Specification
