High Power, High Efficiency 12.9-13.1GHz 120W RF Power Amplifier for Satellite Communication, Microwave Transmission
Place of Origin：China
Brand Name：SWT
Model Number：SW-PA-1290013100-51C
Price：make request to get price
Product Description
High Power, High Efficiency 12.9-13.1GHz 120W RF Power Amplifier for Satellite Communication, Microwave Transmission
The 12.9-13.1GHz 120W RF power amplifier is designed for satellite communication, radar systems, microwave transmission, and RF testing, providing high power, high efficiency, and excellent signal stability.
Key Features:
Operating Frequency: 12.9-13.1GHz, ideal for satellite and radar applications.
High Power Output: 120W (Psat 50.8dBm), ensuring stable long-distance signal transmission.
High Gain & Low Noise: Optimized for minimal distortion and superior signal quality.
Efficient Cooling System: Advanced thermal management supports continuous and stable operation.
Durable & Reliable: Designed for military, aerospace, industrial, and research applications.
This high-performance RF power amplifier is an ideal solution for microwave communication, radar signal amplification, and high-frequency RF applications, ensuring reliable and efficient signal transmission.
Specification
Typical performance at +28VDC +25oC, and in a 50Ω system.
| RF / ELECTRICAL | ||||
| PARAMETER | MIN | TYP. | MAX | UNIT |
| Operating Frequency | 12.9 | 13.1 | GHz | |
| RF INPUT | 0 | dBm | ||
| Power Gain | 51 | dB | ||
| P-1dB Output Power | 51 | dBm | ||
| Power Gain temperature drift | 3 | dB | ||
| In/Out Impedance | 50 | Ω | ||
| Input VSWR | 1.5 | |||
| Spurious Signals | -55 | dBc | ||
| IMD3@Output 42dbm @ two tone space 5MHz | -25 | dBc | ||
| Operating Voltage | 48 | V DC | ||
| Power Dissipation | 1500 | W | ||
Product Details
Name:
12.9-13.1GHz RF Power Amplifier
Operating Frequency:
12.9-13.1GHz
Psat Output Power:
51dBm
Gain:
51dB
Input Vswr:
1.5
Power Gain Flatness:
±1.5dB
Spurious Signals:
-55dBc
Harmonic Signals:
-25dBc
Operating Temp:
-40~60°C
Application:
wireless communications, radar systems, satellite communications, broadcasting, medical equipment
Transport Package:
Carton
Specification:
350*280*80mm
Payment & Shipping Terms
Minimum Order Quantity
1/pcs
Packaging Details
Standard Packing
Delivery Time
5-8 work days
Payment Terms
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability
100pcs per month
