600-960MHz Psat 53dBm High Power UHF Amplifier RF Linear Amplifier For wireless communications, radar system
Place of Origin：China
Brand Name：SWT
Model Number：SW-PA-06000960-53C
Price：
Product Description
600-960 MHz Psat 53 dBm High Power UHF Amplifier RF Linear Amplifier For wireless communications, radar systems
Description
The 600-960 MHz Psat 53 dBm High Power UHF Amplifier is a specialized device designed to amplify radio frequency (RF) signals within the ultra-high frequency (UHF) band, specifically in the frequency range of 600 MHz to 960 MHz. Here's a detailed introduction to this high-power amplifier:
Frequency Range: This amplifier operates within the UHF band, covering frequencies from 600 MHz to 960 MHz. The UHF band is commonly used in various communication systems, including mobile communications, television broadcasting, wireless microphone systems, and industrial applications.
Psat and Power Output: The amplifier provides a Psat (saturated output power) of 53 dBm, which is equivalent to approximately 200 watts (200W) of power. This high-power output level is suitable for applications that require substantial power amplification within the specified frequency range.
Applications: The 600-960 MHz Psat 53 dBm High Power UHF Amplifier finds applications in a wide range of fields, including telecommunications infrastructure, broadcasting stations, RF testing and measurement, wireless data transmission, and industrial RF equipment.
Performance Features: These amplifiers are designed to provide high gain and efficiency while maintaining signal integrity and stability. They often include features such as low noise figure, high linearity, and wide bandwidth to meet the demands of modern RF systems.
Reliability and Durability: High-power UHF amplifiers are engineered for reliability and durability, ensuring long-term performance and robustness in various operating conditions.
Compact Design: Despite their high power output, many high-power UHF amplifiers are designed to be compact and efficient, making them suitable for integration into different systems and applications where space and power consumption are considerations.
In summary, the 600-960 MHz Psat 53 dBm High Power UHF Amplifier is a critical component in RF systems requiring substantial power amplification within the UHF frequency range. It offers high performance, reliability, and versatility, making it suitable for a wide range of communication, broadcasting, testing, and industrial applications that demand significant power output.
Specification
Specifications subject to change without notice. Typical performance at +28VDC +25oC, and in a 50Ω system.
| RF / ELECTRICAL | ||||
| PARAMETER | MIN | TYP. | MAX | UNIT |
| Operating Frequency | 600 | 960 | MHz | |
| RF INPUT | 0 | dBm | ||
| Psat Power Output | 53 | dBm | ||
| Gain | 53 | dB | ||
| Power Gain Flatness | ±1.5 | dB | ||
| In/Out Impedance | 50 | Ω | ||
| Input Return Loss | -15 | dB | ||
| Spurious Signals | -60 | dBc | ||
| Harmonic Signals@ Pout-200W(dB) | -25 | dBc | ||
| Operating Voltage | 220 | AC | ||
| Current@pout: 53 dbm CW | 2 | A | ||
| MECHANICAL | ||
| PARAMETER | VALUE | UNIT |
| Dimensions (W x H x D) | mm | |
| RF Connectors (Input / Output) | SMA- KFD/ N-type Female | -- |
| Control Connector | DB9 | -- |
| AC Connector | XCM | |
| Power indicator light | green(Normal) | |
| Standing wave fault indicator light | red(Alarm ) | |
| Cooling | Heat Sink with Integrated Cooling Fan | -- |
| Mounting | -- | |
| Weight | ≤20 | kg |
| ENVIRONMENTAL / PROTECTIONS | |||
| PARAMETER | MIN | MAX | UNIT |
| Operating Temp. (Housing Temp.) | -22 | +55 | °C |
| Humidity Range | 0-90 | % | |
| Max RF Input | +10 | dBm | |
| PA Baseplate Shutoff Temperature | +85 | °C | |
| High VSWR Protections | Power Amplifier has open/short port protection Configure Input and Output Isolators | ||
| INPUT/OUTPUT PINS | |||
| AMPLIFIER CONNECTOR TYPE: | DB9 | ||
| TRIAD CABLE PART NUMBER: | —— | ||
| PIN NUMBER | LABEL | DESCRIPTION | |
| 1 | Amp Enable | TTL Hi= Enable, TTL Lo = Disable or No Connection | |
| 2 | GND | GND | |
| 3 | FWD | Forward Power Detection (TTL Hi= Normal , TTL Lo =Fault ) | |
| 4 | REV | Reverse Power Detection(TTL Hi= Normal , TTL Lo = Fault ) | |
| 5-9 | NC | NC | |
| INPUT PINS | |||
| AMPLIFIER CONNECTOR TYPE: | XCM | ||
| TRIAD CABLE PART NUMBER: | —— | ||
| PIN NUMBER | LABEL | DESCRIPTION | |
| 1 | L | firing line | |
| 2 | N | null line | |
| 3 | FG | rack earth | |
| Human-computer interaction interface | |
| Human-computer interaction type | 2.8-inch LCD display |
| Output information | Monitoring parameters include: 1,Output power； 2,temperature； 3,Fault information(High VSWR) |
Product Details
Name:
600-960MHz RF Power Amplifier
Operating Frequency:
600-960MHz
Psat Output Power:
200W
Gain:
53dB
Input Vswr:
2
Power Gain Flatness:
±1.5dB
Spurious Signals:
-60dBc
Harmonic Signals:
-25dBc
Operating Temp:
-22~55°c
Application:
EMC Test，Communications, radar system
Transport Package:
Carton
Specification:
483×178×465mm
Payment & Shipping Terms
Minimum Order Quantity
1/pcs
Packaging Details
Standard Packing
Delivery Time
5-8 work days
Payment Terms
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability
100pcs per month
