Customized Low VSWR, low loss, high isolation 18GHz RF coaxial switch for High-Frequency Communication and Microwave System
Place of Origin：China
Brand Name：SWT
Model Number：
Price：
Product Description
Customized Low VSWR, low loss, high isolation 18GHz RF coaxial switch for High-Frequency Communication and Microwave System
Application scenarios
Suitable for high-frequency signal transmission and switching scenarios, especially in the field of radio frequency communication, microwave equipment and radio, where high isolation and low insertion loss are required.
Product Details
Name:
DC to 18GHz coaxial switch
Operating Frequency:
DC to 18GHz
Operating Voltage:
24V/DC
Connector Type:
SMA
lsolation:
60dB
Ins. Loss:
0.4dB
VSWR:
1.4
Application:
High-Frequency Communication and Microwave System
Payment & Shipping Terms
Minimum Order Quantity
1/pcs
Packaging Details
Standard Packing
Delivery Time
5-8 work days
Payment Terms
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability
100pcs per month
