SW-32TRX-P40 Single-channel 10W SIP Transceiver Antenna Subarray
Place of Origin：China
Brand Name：SWT
Model Number：SW-32TRX-P40
Price：Please Contact Customer Service
Product Description
Description
This product is specially designed for high-end RF scenarios such as phased array radar, LEO satellite communication, EW data link, and high-precision navigation systems, enabling efficient RF signal transceiving and beam steering, supporting multi-channel array integration, and meeting the stringent reliability requirements of Industrial, aerospace, and industrial-grade communications.
Specification
submatrix operating frequency | 8.5～9.5GHz |
Module operating frequency | 8～12GHz |
Number of array elements | 16×2 |
Polarization form | linear polarization |
Single-channel amplifier saturation output power | 40dBm |
transmitted input power | +23dBm |
Receive single-channel noise figure | 3.0dB |
Receive small signal gain (single channel) | 20dB |
Receive input P-1 | -30dBm |
Power Supply Voltage | DC+28V |
Submatrix size | 287.8mm×35.8mm×10.5mm |
other | 6 displacement phases, 6 attenuation periods |
X-band Series SIP Transceiver Module Products
Product Details
Packing:
287.8×35.8×10.5mm
Power Consumption:
≈10W
Data Format:
Not specified
Working Temperature:
Not specified
Physical Interface:
Not specified
Communication Interface:
Not specified
Receiving Signal:
NF3.0dB, gain20dB, P-1 -30dBm
Applications:
Not specified
Payment & Shipping Terms
Minimum Order Quantity
1/pcs
Packaging Details
Standard Packing
Delivery Time
5-8 work days
Payment Terms
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability
100pcs per month
